DIMMER PACK RACK 12 CHANNELS 12 AMPERE NEXT DDP 1212 RK WITH TERMINAL SCREW

FEATURES:
• Digital Dimmer Unit with 6 channel DMX 512/1990 standard with possibility of manual control of each channels.
• 3 phases operation 380 Vac 50 Hz + NEUTRAL / Single phase operation 220/240 Vac 50 Hz
• Dip-switch for digital address. (1/512).
• Digital pre-heat control adjustable from 0% to 10% of the power
• LC interference filters: no Audio noise
• DMX-512 with 5 pin XLR male and female input/output.
• Protection against short-circuiting: Should a short-circuit occur, the DDP 612 immediately switches off the channel in question and then attempts to switch it on slowly. If the short-circuit persists for three times, DDP 612 switches the channel off definitely.
• Overload protection: The output is electronically limited to a maximum of 12 A per channel, no matter what load is applied
• Protection against incorrect connections: Through a fuse which blows to avoid overloading damaging of unit's internal circuity.
• Over-Heating protection: The maximum temperature allowed is 90ºC and is measured on the cooling fin. If this temperature is exceeded, the output is disabled until temperature return in the limits
• Forced ventilation: Use of the unit's fans does not in any way compromise the possibility of using the dimmer in locations in which noise has to be kept to a minimum (theaters), DDP 612 uses very low-noise fans which are silent even when operating; their rotation speed is also electronically controlled and directly proportional to the dimmer's internal temperature.
• Power supply: Thanks to his detailled planning, the power supply of the logical part of the DDP 612 is taken from all the three phases. Without presence of one of the three phases the channels powered with the others two phases will work correctly too.
• Dimension (L x H x P) / Weight: 482 x 88 x 275 mm (2U rack) / 8,5 Kg.
