DP-6B INTERFACCIA LITE-PUTER

Lite-Puter designs DP-6B, in order to suit to install in defferent systems (DX-1220, DX-302A, DX-F01 and PX-304). 256 channel DMX signal output. DMX transit in RS-422 mode: the output is connected with DMX dimmer pack, such as DX-1220. RS-485 signal acceptable for connecting with CP-2B/ CP-3B. Can set for 8 separate zones; suitable for room with partitions. Can connect over 10pcs control panels CP-3B, and work as independent control
mode or master-slave mode. 100 scenes can be memorized: each scene controls 256 dimming channels.
Automatic protection for the system when output short and will recover after the short. LCD indicator display ‘year’, ‘month’, ‘day’, ‘week’, ‘hour’, ‘min.’, ‘sec.’ Timer function: the changing steps can be set up to 120 scenes by the minute.
n Fade-in/ Fade-out time: the time setting can be applied for individual scene.(0.1 sec.– 90 min.)
Function of detecting solar light. Signal transit distance: 1km.
- Power Supply: AC90-240V
- DMX signal input: RS485 or DMX512/ 1990
- DMX signal output: DMX512/ 1990
- Transit speed: 250K BITS/ Sec.
- DMX signal connector: XLR 5PIN
